Feature Pump

Bleed Off line

Any time you have a feature pump and you have a pressure cleaner, change the cleaner line to a bleed off line. 1 1/2 PVC Pressure. Just label it as a bleed off line. Run it from cleaner location to pool equipment.

Any time you have a feature pump and you have a suction cleaner, add a bleed off line. 1 1/2 PVC Pressure. Label it as a bleed off line. Run it from cleaner location to pool equipment.

Each feature pump requires a separate bleed off line

⁠

Anything over (2) features requires a 1 HP feature pump and side suction

(2) 2 1/2" suction lines 3' apart and 3’ below water level. T together on outside 2 1/2" suction line back to pump

⁠

⁠

⁠

⁠

A feature is

Spa with spillover

Spillover 36" or wider counts as 2nd feature (needed if client wants spillover to really sheer)

Champagne spa counts as 2 features and requires 1 HP feature pump if there are any other features. It does not require a feature pump if there are no other features.

(1) Bubbler

Deck Jets up to (3)

(1) Waterfall

(1) Sheer Descent

For every additional (2) features add another 1 HP to feature pump

If implementing an infinity edge, feature pump and side suction and extra (2) 2" return line that narrow to 1 1/2" return through pool shell

⁠

⁠
