Infinity Edge/Catch Basin

Infinity Edge cost approximately $1k per linear ft.

Infinity Edge starts at water level and should slope away from the pool at 30 degrees

A Catch Basin is required to capture the water spilling over and recirculate it into the pool.

Catch Basin Requires:

3’ Width and 3’ Water Depth (The water level will actually be much lower. However you need about 3’ depth below waterline.)

3” Catch Basin Main Drain

1.5” Overflow

2” Autofill

⁠
